内容编辑Main Features：
* English OSD menu. * Adopts switch power supply with wide voltage of AC16-30V. * Support outage memory function, the dome will return to the previous PTZ status after powered on. * Rotation speed changed according to the lens zoom value. * Compatible with the following protocols as PELCO-D、PELCO-P 、UTC and so on.
● Technical Data
|
Model |
SGE-H56P18P1-AHD |
SGE-H56P18P2-AHD |
SGE-H56P33P2-AHD |
|
Optical Zoom |
20X |
20X |
33X |
|
COMS Size |
1/3〞COMS 1.3Megapixels |
1/2.8〞COMS 2.1 Megapixels |
|
|
Effective pixels |
1280*720 |
1920*1080 |
1920*1080 |
|
Min. Illumination |
0.1LUX |
0.011LUX |
0.01LUX |
|
Focal Length |
4.7 |
4.7 |
4.6~152mm |
|
IR-CUT |
Auto/ON/OFF |
||
|
Focal Mode |
Auto |
||
|
BLC |
ON/OFF |
||
|
WDR |
ON/OFF |
||
|
WB |
Auto/Manual |
||
|
AGC |
Auto |
||
|
Video Format |
NTSC/PAL |
||
|
S/N Ratio |
≧52dB |
||
|
PTZ Function |
|||
|
OSD language |
English |
||
|
Title Display |
16 characters can be added in each title |
||
|
Max. Pan Speed |
0.05°-320°/s |
||
|
Max. Tilt Speed |
0.05°-240°/s |
||
|
Preset Number |
256 |
||
|
Preset Precision |
±0.1° |
||
|
Pattern Scan |
4（each can record more than 180s） |
||
|
Auto Scan |
4 |
||
|
Tour Group |
4 |
||
|
Compass Function |
Support |
||
|
Speed Changed Proportionally |
Support |
||
|
Communication Mode |
RS485 bus wire |
||
|
Baud Rate |
2400/4800/9600/19200bps |
||
|
Address |
0—255 |
||
|
Outage Memory |
Support |
||
|
Alarm |
4inputs/1output（Customized） |
||
|
Schedule Task |
No |
||
|
Video Output Amplitude |
1.0±0.2Vp-p |
||
|
Video Output |
AHD/TVI/CVI/CVBS Female BNC |
||
|
Other Parameter |
|||
|
Operating Temperature |
|
||
|
Operating Humidity |
0～+95%RH（Non-densing） |
||
|
Protection Grade |
IP66, all-weather housing、3000V lighting and surge proof |
||
|
Power Supply |
AC 24V±20% |
||
|
Power Consumption |
10W（Indoor）,50W（Outdoor） |
||
|
Weight |
|
||
|
Package Dimension |
|
||
