内容编辑Main Features：
Main Features： * Night IR Distance of more than 150M; * Standard H.264; * Continuous Pan: 360°, Tilt: 125° (-40°~+80°); * Pan Max speed: 120°/S; Tilt Max speed: 90°/S; * Withstand wind speed Max 130Km/H; Working speed: 90KM/H; * Support HDTV 1080P/720P, D1 and CIF simultaneous video stream.
Feature：
v Die Casting aluminum alloy structure with water proof, acid rain proof, high temperature proof, anti-aging, anti-corrosion
v H.264 compress format
v Support HD, D1 and CIF simultaneous video stream.
v Controlled by IE browser or customer software
v Support the SDHC and SD card storage
v 256 preset, freeze preset
v Level preset speed can reach 320°/s
v 360°continuously pan and tilt from -80°to +40°, no blind zone.
v With excellent anti-shocking ability, Adapt to all cruel environment and monitor with wiper, heater and fan
v Support multi protocols, TCP/IP、HTTP、DHCP、DDNS、RTSP、 RTP/RTCP、pppoe、FTP、SMTP、NTP、SNMP Onvif
v Support surge &lighting proof
v Protection grade: IP 66 for outdoor
v Working temperature:-30℃ to + 60℃
Technical Date
|
Model |
SGE-H66H30X3-IR |
SGE-H66H30XS-IR |
SGE-H66H30X2-IR |
|
Optical Zoom |
30X |
30X |
30X |
|
Image Sensor |
1/2.8 CMOS, 3 Megapixels |
1/1.9 CMOS,2.4 Megapixels |
1/2.8 CMOS,2.1 Megapixels |
|
Horizontal Resolution |
2048x 1536 |
1920*1080P |
1920*1080P |
|
Min. Illumination |
0.05Lux |
0.005Lux |
0.05Lux |
|
Focal Length |
4.3-129mm |
6-180mm |
4.3 |
|
Visual Angle |
61.4~ 2.9° |
69°- 2.6° |
65.1-2.34 |
|
IR－CUT |
Auto/ON/OFF |
||
|
Focal Mode |
Auto/Manual |
||
|
BLC |
ON/OFF |
||
|
WDR |
ON/OFF |
||
|
Frame Rate |
25P/30P |
||
|
WB |
Auto/Manual |
||
|
AGC |
Auto |
||
|
S/N Ratio |
≧50dB |
||
|
Motion Detection |
ON/OFF |
||
|
Privacy Mask |
Support |
||
|
Other Parameter |
|||
|
IR Distance |
More than 150 meters |
||
|
Max. Pan Speed |
120°/s |
||
|
Max. Tilt Speed |
90°/s |
||
|
Preset Number |
256 |
||
|
Pattern Scan |
4（each can record more than 180s）） |
||
|
Auto Scan |
4 |
||
|
Tour Group |
4（16 preset positions can be added in each group） |
||
|
Speed Changes Proportionally |
Support |
||
|
3D Position Function |
Support |
||
|
Outage Memory |
Support |
||
|
Alarm |
4 inputs/1 output(customized)) |
||
|
Schedule Task |
Support |
||
|
Network Function |
|||
|
Video Compressing Algorithm |
H.265/H.264/MPEG4/MJPEG |
||
|
Video Compressing Code Rate |
64Kpbs～16Mpbs |
||
|
FPS |
7.5fps-30fps |
||
|
Audio Compressing Algorithm |
G．711 |
||
|
Code Stream |
Support Simultaneous Dual Code Stream（720P/D1） |
||
|
Network Protocols |
TCP、UDP、IP、HTTP、RTSP、FTP、DHCP、NTP Onvif |
||
|
Motion Detection |
Support |
||
|
Network Interface |
1个RJ45 |
||
|
Other Parameter |
|||
|
Operating Temperature |
|
||
|
Operating Humidity |
0～90% RH（non-densing） |
||
|
Protection Grade |
IP66 all-weather housing，3000V lighting and surge proof |
||
|
Power Supply |
AC24V/ |
||
|
Power Consumption |
45W |
||
|
Weight |
8KG |
||
|
Package Dimension |
42cm*40cm*43cm |
||
