Name: NVR SGE-8009 HD Network Video Recorder            Item No.: SGE-8009

Main Features：

Key Features: ◆ Can connect IP camera, IP speed dome camera and DVS; support Onvif protocol; ◆ Compatible with main brand IP cameras: AXIS, SONY, Panasonic, SANYO, BOSCH, SAMSUNG, Honeywell, VIVOTEK, HIKVISION, DAHUA, Histream, Grandstream, TOPSEE, Launch, WISION, HYVISION, WAPA etc.; ◆ Support megapixel HD network video preview, storage and playback; ◆ Click any area and zoom in or zoom out on the image by mouse; ◆ Support digital zooming under preview and playback modes; ◆ Support search, playback and backup by event; ◆ Support 4ch playback simultaneously.
NVR SGE-8009 HD Network Video Recorder

1. Preview channel can be switched to other channel randomly without changing the MAC

    which is convenient for the project construction;

2. The dendritic menu can be moved. Man-machine communication is more direct and the

    settings of parameters are more easy and convenient;

3. The mouse roller can realize 15X digital zooming which the enlarged image can be

    dragged and moved randomly under preview and playback modes;

4. Immediate snapshot and immediate view; the picture will be stored in an independent

    area in the HDD;

5. The recording playback is shown by time bar and different color represents different

     recording type. It is very fast and easy to find check the recording;

6. Recording backup can be accurate to second. Any time period of backup is available;

7. The recording files in the USB disk can play directly in the playback interface while the

    snapshot pictures can be viewed directly;

8. With 3G, WIFI wireless connection functions;

9. Standard resolution which can be adjusted according to the display device in order to get

    the best image quality;

10. Adopt HDD sequence writing method and the data is written from 0 track which

    increase 2.5X lifetime of the HDD.



Parameters:



 Model Number

 SGE-8009

 Operating System

 Embedded LINUX operating system

 Image Code Control

 Image code quality adjustable, variable bitstream and constant bitstream optional

 Dual Stream

 Each channel can set main stream and sub stream

 Video Standard

 1080P(1920×1080)fps / 720P(1280×720)30fps

 Monitoring Image Quality

 1080P(1920×1080) / 720P(1280×720)

 Image Motion Detection

 Each screen can set mutiple detection areas and set 6-level sensitivity

 Recording Playback Quality

 Any 4ch 1080P/720P playback simultaneously

 Region Cover

 Every channel can set 4 cover regions

 Recording Mode

 Support manual , auto, dynamic detection, alarm trigger record mode

 Backup Way

 Support U disk, USB mobile HDD, USB DVD-RW .

 network storage and backup

 Operation Way

 Mouse, remote control, front panel, keyboard controller

 Local Login

 User name and password

 Recording Storage

 Local HDD, network

 External

 Ports

 Video Input

 9×(1280*720) IP camera

 2×(1920*1080) +4×(1280*720) IP camera

 4×(1920*1080) IP camera

 Audio Input

 9/6/4ch network audio input

 Video Output

 1ch VGA+1ch HDMI

 Audio Output

 1ch BNC auxiliary output

 Network Port

 1 RJ45,10M/100M/1000M self-adaptive LAN port

 RS485 Port

 Full duplex standard 485 port, support 19 kinds of PTZ protocols

 USB Port

 3 USB 2.0 ports(one on front panel, two on rear panel)

 Alarm Input

 16ch

 Alarm Output

 4ch

 Wireless Port

 3G，WIFI

 HDD

 HDD Port

 2 SATA HDD port/1 SATA+1 E-SATA

 MAX Capacity

 Each port supports MAX 3TB HDD

 Mobile Surveillance

 Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone

 Power Supply

 12V4A

 Power Consumption

 ≤25W（without HDD）

 Working Temperature

 -10℃～＋55℃

 Working Humidity

 10％-90％

 Dimension

 Equipment: 350mm×240mm×70mm，

 Packing: 409mm×365mm×129mm

 Wight(without HDD)

 N.W.: 1.7Kg；with packing:2.89Kg

 Outside Carton

 5pcs/carton. 675mm×425mm×385mm；weight: 15.22 Kg.

 Installation Way

 Desktop installation
