内容编辑Name: NVR SGE-8004 HD Network Video Recorder Item No.: SGE-8004
Main Features：
Key Features: ◆ Can connect IP camera, IP speed dome camera and DVS; support Onvif protocol; ◆ Compatible with main brand IP cameras: AXIS, SONY, Panasonic, SANYO, BOSCH, SAMSUNG, Honeywell, VIVOTEK, HIKVISION, DAHUA, Histream, Grandstream, TOPSEE, Launch, WISION, HYVISION, WAPA etc.; ◆ Support megapixel HD network video preview, storage and playback; ◆ Click any area and zoom in or zoom out on the image by mouse; ◆ Support digital zooming under preview and playback modes; ◆ Support search, playback and backup by event; ◆ Support 4ch playback simultaneously.
1. Preview channel can be switched to other channel randomly without changing the MAC
which is convenient for the project construction;
2. The dendritic menu can be moved. Man-machine communication is more direct and the
settings of parameters are more easy and convenient;
3. The mouse roller can realize 15X digital zooming which the enlarged image can be
dragged and moved randomly under preview and playback modes;
4. Immediate snapshot and immediate view; the picture will be stored in an independent
area in the HDD;
5. The recording playback is shown by time bar and different color represents different
recording type. It is very fast and easy to find check the recording;
6. Recording backup can be accurate to second. Any time period of backup is available;
7. The recording files in the USB disk can play directly in the playback interface while the
snapshot pictures can be viewed directly;
8. With 3G , WIFI wireless connection functions;
9. Standard resolution which can be adjusted according to the display device in order to get
the best image quality;
10. Adopt HDD sequence writing method and the data is written from 0 track which
increase 2.5X lifetime of the HDD.
Parameters:
|
Model Number
|
SGE-8004
|
|
|
Operating System
|
Embedded LINUX operating system
|
|
|
Image Code Control
|
Image code quality adjustable, variable bitstream and
|
|
|
Dual Stream
|
Each channel can set main stream and sub stream
|
|
|
Video Standard
|
1080P(1920×1080)fps / 720P(1280×720)30fps
|
|
|
Monitoring Image Quality
|
1080P(1920×1080) / 720P(1280×720)
|
|
|
Image Motion Detection
|
Each screen can set mutiple detection areas and set 6-level
|
|
|
Recording Playback Quality
|
Any 4ch 1080P/720P playback simultaneously
|
|
|
Region Cover
|
Every channel can set 4 cover regions
|
|
|
Recording Mode
|
Support manual , auto, dynamic detection, alarm trigger
|
|
|
Backup Way
|
Support U disk, USB mobile HDD, USB DVD-RW .
network storage and backup
|
|
|
Operation Way
|
Mouse, remote control, front panel, keyboard controller
|
|
|
Local Login
|
User name and password
|
|
|
Recording Storage
|
Local HDD, network
|
|
|
External
Ports
|
Video Input
|
1×(1920*1080) +3×(1280*720) IP camera
|
|
Audio Input
|
4ch network audio input
|
|
|
Video Output
|
1ch VGA+1ch HDMI
|
|
|
Audio Output
|
1ch BNC auxiliary output
|
|
|
|
1 RJ45,
|
|
|
RS485 Port
|
Full duplex standard 485 port, support 19 kinds of PTZ
|
|
|
|
3 USB 2.0 ports(one on front panel, two on rear panel)
|
|
|
Alarm Input
|
4ch
|
|
|
Alarm Output
|
1ch
|
|
|
|
|
|
|
HDD
|
|
2 SATA HDD ports/1 SATA+1 E-SATA
|
|
MAX Capacity
|
Each port supports MAX 3TB HDD
|
|
|
Mobile Surveillance
|
Support( iPhone, Windows Mobile, BlackBerry, Symbian,
|
|
|
Power Supply
|
12V
|
|
|
Power Consumption
|
≤25W（without HDD）
|
|
|
Working Temperature
|
|
|
|
Working Humidity
|
10％-90％
|
|
|
Dimension
|
Equipment:
Packing:
|
|
|
Wight(without HDD)
|
N.W.:
|
|
|
Outside Carton
|
5pcs/carton.
|
|
|
Installation Way
|
Desktop installation
|
|
